Near InfraRed analyzer for process
High performance
Low cost

• High stability of measure with a double beam
  optical system, avoiding any drift of the
  analyzer.
• The system is indifferent to:
  - temperature
  - grain size
  - measuring distance
• High speed and large measuring area for
  moving product
• Quick and easy installation, supplied calibrations
  and simply correction

A large range of products can be measured in any kind of industry. Accuracy is 1% or better depending of the product (1% of the maximum value of measurement range).

Features Measuring system Infrared reflection with 4 wavelenghts   double beam system (reference and product) Measuring area 60 mm diameter at a distance of 200 mm Measuring distance 120 to 300 mm (180 mm typique) Measuring speed 1 measure in 12,5 ms Smoothing linear or exponentiale  0,1 to 180 s Analog output 0(4)-20 mA  +/- 0,2% of full scale   500 ohms maximum load Communication 2 RS485 ports  (PC and display unit) Calibration 31 calibration curves Working temperature 0 à 40 °C without cooling   > à 40°C  with air cooling   > à 50°C with water cooling Dimensions 130 x 149 x 277 mm Weight 5 kg Power supply 24 VDC (22V à 28V) /35 VA Case IP65
